Vacuum Suction Cup PA, PB, PC, PE, PF, PJ, PN, PU, PW series
Vacuum Suction Cup PA, PB, PC, PE, PF, PJ, PN, PU, PW series
• Function：Vacuum suction cups can move, place, position, rotate, etc.objects and are often used in automation mechanisms.
• Type：PA, PB, and PC series vacuum suction cups include PAG single-layer thin type, PEG single-layer type, PFG single-layer type, PUG single-layer shaking head type, PNG single-layer/double-layer type, PJG double-layer type, PBG double-layer type, PCG three-layer thin suction cup.
• Material：NBR(Nitrile Rubber), SICICONE, FKM(Fluoro Carbon Rubber), etc.
• Applied industry：Applied to paper, plastic plates, steel plates, balls, curved workpieces, food preparation bags, quartz, wafers, optoelectronics, packaging, medical equipment, etc.
| Model | Structural Features | Material Options | Suitable Workpieces | Common Applications |
|---|---|---|---|---|
| PA Series | Lightweight design with fast suction and release | NBR, SICICONE, FKM, etc. | Small or precision parts | Semiconductor, optical components, automated assembly |
| PB Series | Reinforced structure with high pressure resistance and long lifespan | NBR, SICICONE, FKM, etc. | Heavy objects, metal sheets, construction materials | Automated handling, machining lines |
| PC Series | High-flexibility bellows structure for better compensation | NBR, SICICONE, FKM, etc. | Curved or uneven surfaces | Electronic assembly, automotive parts |
| PE Series | Ultra-thin design, fast response time | NBR, SICICONE, FKM, etc. | Films, labels, plastic sheets | Packaging, automatic labeling lines |
| PF Series | Thick lip design with excellent sealing performance | NBR, SICICONE, FKM, etc. | Rough or porous surfaces | Wood panels, cartons, foam materials |
| PJ Series | Deep cup structure with strong suction force | NBR, SICICONE, FKM, etc. | Irregular or 3D-shaped workpieces | Electronic parts, molded plastic components |
| PN Series | Multi-bellows structure with high compensation capability | NBR, SICICONE, FKM, etc. | Height-difference or curved surfaces | Semiconductor, glass industry |
| PU Series | Soft and durable material with high wear resistance | NBR, SICICONE, FKM, etc. | Smooth or fragile surfaces | Precision handling, food packaging |
| PW Series | Wide flat surface design for stable suction | NBR, SICICONE, FKM, etc. | Large flat workpieces | Sheet materials, glass, panels |
