Vacuum Suction Cup and Pad Manufacturer

Vacuum pad manufacturer

【Vacuum Suction Cups Manufacturer】AND【Vacuum Pad Supplier】

CNL SEALS is a specialized vacuum cup and pad manufacturer and Suction cup product. Vacuum cups are the most common and economical seals. Materials of vacuum cups and pads: NBR, SILICON, FKM, ESD NBR/SILICON, EPDM... Custom molded products and die-cuts. Vacuum cups are suitable for use in static and dynamic applications. CNL's vacuum cups and pads are high-quality and the best choice for static and dynamic applications.

Table of Contents

【Vacuum Suction Cup Product】Vacuum Suction Cup Types(Material)

▍Silicone Vacuum Suction Cups

With Silicone main chain from silicon (-si-o-si) combined chemical structure. Silicone Vacuum Suction Cups features are heat-resistant, cold, non-toxic, with good electrical insulation properties, not resistant to oil, ozone and solvents.

▍Viton Vacuum Suction Cups (FKM Vacuum Suction Cups)

Fluorocarbon Rubber Vacuum Suction Cup with hexafluoropropylene fluoroethylene copolymer chemical structure. Fluoro Carbon Rubber Vacuum Suction Cup features are heat-resistant, oil-resistant, chemical-resistant, solvent-resistant; not resistant to ketones, esters and nitrate-containing mixtures.

▍Nitrile Vacuum Suction Cups (NBR Vacuum Suction Cups)

With butadiene, acrylic gel copolymer chemical structure. Nitrile rubber Vacuum Suction Cups features are oil resistant, water resistant, abrasion resistant, high oil pressure resistant, non-polar solvent resistant.

▍EPDM Vacuum Suction Cups (EPDM, EPT)

With ethylene and propylene copolymer (terpolymer) chemical structure. Ethylene Propylene Rubber features are anti-aging, ozone resistance, weather resistance, chemical resistance, abrasion resistance, water resistance, alcohol resistance and ketones, not for food use or exposure to aromatic hydrogen. CNL EPDM Vacuum Suction Cups specifications and compatibility.

Vacuum Pads Industry | View Vacuum Suction Cups Catalog and Prodcuts

Vacuum Suction Cups and Pads Offerings List

【Vacuum Cups Options】Vacuum Suction Cup for S1, S2, S3, S5, S0 type

▍Best Vacuum Pads | Vacuum Suction Cup S1 type

CNL offer a wide range sizes, shapes and materials of vacuum pads options to meet all handling and transfer needs.
The pads diameters are available from 0.4 to 150mm.
NBR, SILICON, FKM, ESD NBR/SILICON material are available.

Vacuum Suction Cup S1 Type Specifications

Vacuum Cup S1 Type SizeMaterial OptionsTypical ApplicationsFeatures
0.2 ~ 3 mmNBR, SiliconeHandling small componentsHigh flexibility, good sealing
4 ~ 5 mmNBR, Silicone, UrethaneElectronic parts handlingDurable, resistant to wear
6 ~ 7 mmSilicone, UrethaneGlass handlingNon-marking, soft contact surface
8 mmNBR, SiliconeSheet metal handlingHeat resistant, oil resistant
9 ~ 10 mmSilicone, UrethaneAutomotive assemblyHigh temperature resilience
11 ~ 14 mmNBR, UrethanePackaging industryStrong suction, easy manipulation
15 ~ 16 mmSilicone, UrethaneFood and beverage industryFDA approved materials
17 ~ 20 mmNBR, UrethaneAppliance manufacturingVersatile applications, durable
20 ~ 25 mmSilicone, NBRWindow and door assemblySuperior hold, high flexibility
26 ~ 30 mmSilicone, UrethaneConstruction and stoneHeavy-duty use, high load capacity

▍Vacuum Pads industrial Supply | Vacuum Suction Cup S2 type

1.5 bellow cup is suitable for irregular, curved surfaces, flexible sheets, smooth or different height. Soft sealing lip can contact surfaces well.
The pads diameters are available from 3 to 80mm.
NBR, SILICON, FKM, ESD NBR/SILICON material are available.

Vacuum Suction Cup S2 Type Specifications

Vacuum Cup S2 Type SizeMaterial OptionsTypical ApplicationsFeatures
3 ~ 7 mmNBR, Silicone, UrethaneHandling small, delicate componentsFlexible, with good sealing properties
8 ~ 11 mmSilicone, NBRElectronic assembly, automotive parts handlingHigh temperature resistance, durable
11 - 20 mmFKM, SiliconeAppliance manufacturing, food processingFDA compliant, oil resistant
21 - 30 mmNBR, FKM, SiliconeConstruction and heavy machineryHeavy-duty use, high load capacity

▍Vacuum Suction Cup Selection | Vacuum Suction Cup S3 type

Minimize contact to the products. Soft seal lip will conform to the products surface well, especially for highly irregular surfaces.
The pads diameters are available from 4 to 90mm.
NBR, SILICON, FKM, ESD NBR/SILICON material are available.

▍Vacuum Suction Cup Manufacturer | Vacuum Suction Cup S4, S5 ultple type

The same applications as S2 and S3 series. Suitable for different level.
The pads diameters are available from 4 to 90mm.
NBR, SILICON, FKM, ESD NBR/SILICON material are available.

▍Vacuum Cup Supplier | Vacuum Suction Cup S0 type

This series are in closed ring shape or semi-ring shape. It is suitable for common use on CDs, DVDs or Blu-ray disk production.
The pads diameters are available in diameters from 6 to 114mm.
NBR, SILICON, FKM, ESD NBR/SILICON material are available.

Vacuum Cup for ZP, VP, PJG

▍Vacuum Suction Cup Products | Vacuum Suction Cup ZP type

The shape is based on OE ZP type.
NBR, SILICON, EPDM, FKM, ESD NBR/SILICON are acceptable.
Color and hardness can up to your design.

▍Vacuum Cup Selection | Vacuum Suction Cup VP type

The shape is based on OE VP type.
NBR, SILICON, EPDM, FKM, ESD NBR/SILICON are acceptable.
Color and hardness can up to your design.

▍Vacuum Suction Cup Selection | Vacuum Suction Cup POG type

The shape is based on OE P-A, B, BO, C, D, E, F, FO, H, J, K, N, R, U, W-G and PUGB type.
NBR, SILICON, EPDM, FKM, ESD NBR/SILICON are acceptable.
Color and hardness can up to your design.

Vacuum Suction Cup POG Type Specifications

ModelSize (Pad x Adaptor x Height)MaterialsFittings
S1-PAG-5B2*5*4NBR, Silicon, EPDM, FKM, ESD NBR/SiliconA3B-123, B3B-124
S1-PNG-1016.5*31*11NBR, Silicon, EPDM, FKM, ESD NBR/SiliconA6X-130, A6X-131
S1-PEG-82.5*8*12NBR, Silicon, EPDM, FKM, ESD NBR/SiliconStandard fittings
S1-PFG-83.8*15*4.5NBR, Silicon, EPDM, FKM, ESD NBR/SiliconA5X-144, A5T-039
S1-PJG-154.7*17.6*10NBR, Silicon, EPDM, FKM, ESD NBR/SiliconA5Y-120

▍Vacuum Pad Products | Vacuum Suction Cup PIAB1 type

The shape is based on PIAB1 type.
NBR, SILICON, EPDM, FKM, ESD NBR/SILICON are acceptable.
Color and hardness can up to your design.

【Vacuum Pad Selections Guide】Oval, Square,Sponge Vacuum Pad, Peek & Antistatic Vacuum PadVacuum Cup with Fitting

▍Oval Vacuum Pad

NBR, SILICON, FKM, ESD NBR/SILICON material are available.

▍Vacuum Pad Products | Square Vacuum Pad

NBR, SILICON, FKM, ESD NBR/SILICON material are available.

▍Vacuum Pad Material Selection | Peek Vacuum Pad

▍Vacuum Pad Material Selection | Sponge Vacuum Pad

▍Vacuum Pad Replacement | No-mark Vacuum Pad

▍Vacuum Cup Supplier | Vacuum Cup with Fitting

Barb fittings are also available.
Buffers with spring can absorb the impacts and adjust the different levels of pick up articles.

【Vacuum Pad Selection Guide】Vacuum pads FAQ

What are the typical applications and functionalities of vacuum pads?

Also named Suction cups, Vaccum cups and vacuum grippers, It use vacuum principle to absorb the workpiece in order to achieve the purpose of moving the workpiece. It used to move the objects or grip the products.
Selecting the type of vacuum pads must consider the operating temperature, stroke, speed, pressure, in order to achieve the most appropriate results.

What are the key features and benefits of using vacuum pads?

  1. EASY LOSS: Most vacuum pads types made of rubber. It contacts the objects directly, therefore, it easy to wear and loss quickly.
  2. EASY USE: No matter what material object need to be sucked, only if it can seal and can be used.
  3. WITHOUT POLLUTION: There are no light, heat, electromagnetic and other pollution.
  4. CANNOT HURT THE WORKPIECE: It is made of rubber material. It will not cause any harm to the workpiece when gripping or laying down the workpiece , but not for hook spreader and cable type spreader.

What factors should be considered when selecting the appropriate vacuum pads for industrial use?

  1. The adsorption area of workpiece determine the pad diameter and number of pads. If the workpiece is big, taking into consideration the balance of the workpiece, idendiry the adsorption positioning and distribute the pads reasonable.
  2. Selecting the type of suction pads based on the the transferred object and surface condition such like permeability, anti-static, resistance to copper ions, absorption shape, absorption area, flatness…… and so on.
  3. According to different temperature to select different pad material. Recommended the use of silicone (SI) material or polyurethane (PU) material in high temperature environment ; using natural rubber (NR) material in low temperature environment.
  4. Connection - vacuum pad, connector, connector with buffer.
  5. To transfer from different level - horizontal lifting or vertical lifting.
  6. Stroke Dimensions .

What is an ESD vacuum pad and why is it important?

Electrostatic causes: friction, peel, induction……and etc.
The substance is charged by loss or gain of electrons.

How does ESD discrimination classify different levels of static resistance?

ESD discriminate three levels as below:

  1. ANTI-STATIC:
    SURFACE ELECTRIC RESISTANCE 109~1012
  2. Electrostatic dissipative:
    SURFACE ELECTRIC RESISTANCE 106 ~ 109Ω
  3. Conductive:
    SURFACE ELECTRIC RESISTANCE 104~106Ω
    DIN IEC 1340-4-1 request antistatic material level is 106~109Ω

Why is it necessary to use anti-static dissipative materials in certain environments?

People walking or friction, is the main source of static electricity. Static electricity build-up can cause electric shock or damage to the precision equipment.
EX: Most moden offices use the central air-conditioning, which use all day will make the air more dry and will cause static electricity easy to produce, gathered and not easy to dissipate.

What are the advantages of using conductive grade materials in sensitive environments?

In the high-precision space, such as wafer production line, operation room, ammunition depot……and etc. The static electricity can not be gathered. It must be discharge via static-conducting agent in order to avoid danger.
EX: Doctors need to monitor a variety of index on precision instruments. If the computer and the instrument are interfered due to static and make the reading is not correct. It may lead to a doctor misjudgment and results in irreparable error.

What are the ideal applications for ESD vacuum pads and their respective classifications?

Electro Static dissipative: Suitable for offices, schools, hospitals, public indoor places, factory offices, processing factory.
Conductive: Suitable for surgery room, ammunition depots, IC equipment, wafer production lines, and other precision plant.

What types of anti-static materials does CNL offer and what are their specifications?

  1. Conductive:
    SURFACE ELECTRIC RESISTANCE 104~106Ω
  2. Electro Static dissipative:
    SURFACE ELECTRIC RESISTANCE106~109Ω

What are the material options available for anti-static vacuum pads from CNL?

  1. Silicon
  2. NBR

CNL will use a professional surface resistance measuring instruments to test materials and finished products during the manufacture and QC to sure to meet the above two levels.
These antistatic materials are widely used in vacuum suction cups in order to prevent the production line free from the static electricity and cause product damage.

Static Electricity Is The Killer Of The Electronics Industry

Electrostatic causes in many ways, such as contact, friction, and so on.
The process can be summarized as: contact → charge → transfer → charge layer formation → charge separation.
Equipment or human body cause the electronics up to tens of thousands of volts or even hundreds of thousands of volts, even under normal operating conditions are often caused hundreds to thousands of volts.
The human body due to its own action and contact with other objects - separation, friction or induction and other factors, can bring thousand volts or even tens of thousands of volts of static electricity.
Static electricity is the result of positive and negative charge lose balance.
It is a kind of performance in the object with electric energy. The featuress are high potential, low power, small current and short acting time.

▍It differentiates hard breakdown and soft breakdown.

  1. Hard breakdown causes dielectric breakdown, burnout or permanent failure in one-time.
  2. Soft breakdown is caused by the performance degradation of the device or parameter indicator.
